Aluminium Composite Panel (ACP)

Aluminum Composite panel is composed of non combustible polyethylene core laminated and sandwiched between two fine aluminum sheets. The external aluminum surface is coated with superior quality PVDF resin to ensure durability, stability, corrosion and weather resistance. The inside aluminum surface is polyester coated ensuring smooth surface.

Thickness: ACP Sheets are available in 3mm and 4mm thickness. Considering the whether conditions / Load Bearing conditions and customer choice, the thickness of the sheets are considered.

Color: ACP Sheets are available in wide range of colors, Wooden grain patterns are also available to meet the interior and exterior Themes of the elevation patterns.

Salient features of ACP

General Construction

Aluminum Composite panel cladding is done, using 2" x 1" plain rectangular tube, ACP Sheet, 3M Adhesive tape, weathering sealant and quality hardware’s. OR all the ACP sheets are initially fabricated into Trays before erection to the aluminum frame structure.

Frame work is made, matching to the elevation and rigidly fixed to the building by means of expansion bolts. The ACP sheet is fixed to the frame with 3M tape. All the joints of the ACP sheet is finished with weather proofing DOWCORNING 789 sealant.

Aluminum frame work is made of 2" x 1" rectangular tube manufactured as per IS 63400. Make : JINDAL or equivalent.
